HXY-A10气胀工作救生衣

HXY-A10气胀工作救生衣--苏州海星海事装备股份有限公司
HXY-A10气胀工作救生衣
  • 询价
适用范围
适用于国内渔船和远洋渔船。
认可标准
《渔业船舶法定检验规则》(2000)及其修改通报; SC/T8149-2015《渔业船舶用气胀式工作救生衣》。
产品技术参数
形式:单气室
气室材料:TPU
CO2气瓶重量:33g
充气时间:<5S
使用环境温度:-30'C〜+65°C
浮力:>100N
浮力损失:<5%
适合身高:>15 5CM
适合保重:>43KG
配件:口哨和提拉襟
HXY-A10 Inflatable Working Lifejacket
The scope of application
Applied to Domestic fishing vessels and Overseas fishing vessels
Approval Standard
Rules of Statutory Survey of Fishing Vessel (2000)and its Amendments SC/T8149-2015 Working inflatable lifejacket for fishing vessel
Product specifications
Type: One compartment
Compartment Material: TPU
Co2 Cylinder wei^it: 33g
Inflation time: < 5S
Usage environment temperature: -30°C —65°C
Buoyancy: > 100N
Buoyancy Loss: < 5%
Fitforhei^it: >155CM
Fit for weight: >43KG
Accessories: whistle and lifting becket

编码Code

认证 Approval

型号Model

060102019

CCS

HXY-A10

装箱数QTY

包装尺寸Size (cm)

毛重 Gross weight(kg)

10

62*32*30

11.5



1. 打开拉链,将一只胳膊伸入救生衣内。
2. 然后将另一只胳膊伸入救生衣内,拉好拉链并插好插扣。
3. 整理衣服,调整带子松紧度至自己舒服为止。
4. 直接入水:溶解栓遇水自动发生溶解反应,使膨胀装置动作刺穿气瓶往气囊中充入二氧化碳气体
充气入水:右手用力下拉手动拉绳使膨胀装置动作刺穿气瓶往气囊中充入二氧化碳气体。
5. 如果浮力不够的情况下,可从吹具管中往具囊里吹入气体。
1. Zip up life jacket and stretch one arm into life jacket
2. Put the other arm into Hfe jacket, zip up life jacket and fasten buckles.
3. Sort out life jacket, and adjust straps to the proper position.
4. Direct use: the dissovling plug dissolves automatically when it meets with water, which makes the expansion device act to pierce the 序s cylinder and fill the air bag with carbon dioxide.Use after Inflation: pull sharply on the cord with your ti曲t hand, which makes the expansion device act to pierce the gas cylinder and fill the air bag with carbon dioxide.
5. In case of insufficient buoyancy, please blow ait into airbag throu^i air tube.
