HXY-A11 救生衣

HXY-A11  救生衣

适用范围

适用于船舶或救援使用

认可标准

ISO12402-3:2020

产品技术参数

形式：固体+双气囊双气室

外包布料：300D牛津布PVC涂层

气囊料：尼龙TPU复合

浮力材料：聚乙烯泡沫

二氧化碳气瓶：17G*2

口吹管：TPU

重量：≤1.7kg

固体浮力：≥75N

气囊浮力：≥75 N

总浮力：≥150N

24小时后浮力损失：≤5%

适合身高：≥155cm

适合体重：≥43kg

充气成型时间：≤5s

使用环境温度： -30℃~+65℃

配件：口哨、伙伴绳、提拉环。

HXY-A11 Lifejacket

The Scope Of Application

Adopt to Suitable for vessel or rescue use

Approval Standard

ISO12402-3:2020

Product   Specifications

Type:solid+double airbags and double chambers  Wrapping clot:300D oxford with PVC coating

Clothing of chamber:Nylon with TPU coating

Buoyant material:Polyethylene foam

CO2    cylinder:17G*2

Oral  inflation  tube:TPU

Weight:≤1.7kg

Solid buoyancy:≥75N

Solid buoyancy:≥75N

Buoyancy:≥150N

Buoyancy loss after 24hours:≤5%

Suitable    Suitable    Inflatable

height:≥155cm

weight:≥43kg

molding time:≤5s

Operating environment:-30℃~+65℃

Accessories:whistle 、buddy line and lifting becket

1.打开拉链，将一只胳膊伸入救生衣内。

2.然后将另一只胳膊伸入救生衣内，拉好拉链扣好腰扣及档扣。

3.整理衣服，调整带子松紧度至自己舒服为止。

4. 直接入水：溶解栓遇水自动发生溶解反应，使膨胀装置动作刺穿气瓶往气囊中充入二氧化碳气体。

充气入水：右手用力下拉手动拉绳，使膨胀装置动作刺穿气瓶往气囊中充入二氧化碳气体。

5.如果浮力不够的情况下，左手下拉手动绳打开第二个气囊，或从吹气管中往气囊里吹入气体。

1.Zip up life jacket and stretch one arm into life jacket.

2.Put the other arm into life jacket,zip up life jacket and fasten buckles.

3.Sort  out  life jacket,and  adjust  straps  to  the proper position.

4.Direct use:the dissovling plug dissolves automaticaly when it meets with water,which makes the expansion device act to pierce the gas cylinder     and fill he air bag with carbon dioxide.Use after Inflation:pullsharply on the cord with your right hand,which makes the expansion device act to   pierce the gas cylinder andfill the air bag with carbon dioxide.

5.In case of insuffcient buoyancy,pull on the cord with your left hand to open the second airbag,or blow air into airbag through air tube.
